Brother HL-5590DN Service Manual

5-17
Confidential
<Solenoid and clutch check>
Check the corresponding solenoid and clutch by activating the sensor below.
Both solenoid and clutch can not detect error or fault. They only check if they are functioning.
E2 T2TT paper feed sensor TT paper tray 2 closed
and No paper
TT paper tray 2 open
and Paper set
D2 T2TT paper empty sensor No paper Paper set
E3 T3TT paper feed sensor TT paper tray 3 closed
and No paper
TT paper tray 3 open
and Paper set
D3 T3TT paper empty sensor No paper Paper set
E4 T4TT paper feed sensor TT paper tray 4 closed
and No paper
TT paper tray 4 open
and Paper set
D4 T4TT paper empty sensor No paper Paper set
E5 T5TT paper feed sensor TT paper tray 5 closed
and No paper
TT paper tray 5 open
and Paper set
D5 T5TT paper empty sensor No paper Paper set
J2 T2 JAM sensor No paper Paper set
J3 T3 JAM sensor No paper Paper set
J4 T4 JAM sensor No paper Paper set
J5 T5 JAM sensor No paper Paper set
AL TT balance sensor L With attachment No attachment
AR TT balance sensor R With attachment No attachment
Sensor operation Solenoid/clutch operation
Change the status of the T1 paper feed sensor from
Paper tray 1 open to Paper tray 1 closed.
The T1 pickup clutch remains ON
for the specified time.
Change the status of the T2LT paper feed sensor from
Paper tray 2 open to Paper tray 2 closed.
The T2LT pickup clutch remains ON
for the specified time.
Change the status of the T2LT paper empty sensor from
No paper to Paper set.
The T2 LT release clutch remains ON
for the specified time.
Change the status of the T3LT paper feed sensor from
Paper tray 3 open to Paper tray 3 closed.
The T3LT pickup clutch remains ON
for the specified time.
Change the status of the T3LT paper empty sensor from
No paper to Paper set.
The T3LT release clutch remains
ON for the specified time.
Change the status of the T4LT paper feed sensor from
Paper tray 4 open to Paper tray 4 closed.
The T4LT pickup clutch remains ON
for the specified time.
Change the status of the T4LT paper empty sensor from
No paper to Paper set.
The T4LT release clutch remains
ON for the specified time.
Change the status of the MP paper empty sensor from
No paper to Paper set.
The MP solenoid remains ON for
the specified time.
LCD Sensor name
Detection status
With display No display
