5-19

Confidential

 Location of sensors

Fig. 5-8

Toner amount detection sensor PCB (light reception)

Eject sensor

Eject stack sensor

Registration front/rear sensor

MP paper empty

sensor

T1 paper empty sensor

LT paper feed sensor

LT paper empty sensor

Front cover sensor

T1 paper feed sensor

Internal temperature sensor

Toner amount detection sensor PCB

(light emission)

Back cover/duplex

tray sensor

New toner sensor
