5-20

Confidential

Fig. 5-9

Fig. 5-10

MX 2bin sensor

MX 1bin stack sensor

MX 4bin sensor

MX 2bin stack sensor

MX 3bin stack sensor

MX 4bin stack sensor

MX JAM lower sensor

MX JAM upper sensor

MX back cover sensor

TT jam sensor PCB ASSY

TT paper feed sensor

PCB ASSY

TT balance sensor L

TT jam sensor

PCB ASSY

TT jam sensor

PCB ASSY

TT paper feed sensor

PCB ASSY

TT paper feed sensor

PCB ASSY

TT paper empty

sensor PCB ASSY

TT paper feed sensor

PCB ASSY

TT paper empty

sensor PCB ASSY

TT paper empty

sensor PCB ASSY

TT jam sensor PCB ASSY

TT balance sensor R

TT paper empty sensor PCB ASSY
