Brother HL-5590DN Service Manual

2-36
Confidential
Output Tray Full - MX 1bin, 2 bin , 3 bin , or 4 bin stack
sensor or machine stack sensor
detected the ejected paper full state
at the start of printing.
8701 2-72
Machine stack sensor detected the
eject paper full state at the start of
printing when the machine output
tray was selected as the output tray.
8702 2-73
MX 1bin stack sensor detected the
eject paper full state at the start of
printing when the MX 1bin was
selected as the output tray.
8708 2-73
MX 2bin stack sensor detected the
eject paper full state at the start of
printing when the MX 2bin was
selected as the output tray.
8709 2-73
MX 3bin stack sensor detected the
eject paper full state at the start of
printing when the MX 3bin was
selected as the output tray.
870A 2-73
MX 4bin stack sensor detected the
eject paper full state at the start of
printing when the MX 4bin was
selected as the output tray.
870B 2-73
Machine stack sensor or MX 1bin
stack sensor detected the eject
paper full state at the start of printing
when the MX 1bin was selected as
the output tray and "Use Std. Tray
when full" setting was ON.
870C 2-74
Machine stack sensor or MX 2bin
stack sensor detected the eject
paper full state at the start of printing
when the MX 2bin was selected as
the output tray and "Use Std. Tray
when full" setting was ON.
870D 2-74
Machine stack sensor or MX 3bin
stack sensor detected the eject
paper full state at the start of printing
when the MX 3bin was selected as
the output tray and "Use Std. Tray
when full" setting was ON.
870E 2-74
Machine stack sensor or MX 4bin
stack sensor detected the eject
paper full state at the start of printing
when the MX 4bin was selected as
the output tray and "Use Std. Tray
when full" setting was ON.
870F 2-74
Error message
Description
Error
codes
Refer
to:
First line Second line
