Brother HL-5590DN Service Manual

2-37
Confidential
Paper Low Paper Low Tray 1 Detected that the paper is running out
when the paper feed motor drive and
T1 paper empty sensor turned ON.
--- 4.11.4
Paper Low Tray 2
Detected that the paper is running
out when the paper feed motor,TT
motor drive and T2(LT or TT) paper
empty sensor turned ON.
--- 4.11.4
Paper Low Tray 3
Detected that the paper is running out
when the paper feed motor,TT motor
drive and T3(LT or TT) paper empty
sensor turned ON.
--- 4.11.4
Paper Low Tray 4
Detected that the paper is running out
when the TT motor drive and T4TT
paper empty sensor turned ON.
--- 4.11.4
Paper Low Tray 5
Detected that the paper is running out
when the TT motor drive and T5TT
paper empty sensor turned ON.
--- 4.11.4
Print Data Full
Secure Print Data is full.
Press Stop[x] Key and
delete the previously
stored data.
The memory size allotted for
Secure Print was exceeded when
saving Secure Print data.
C800 2-82
Print Unable 01 Turn the power off and
then back on again.
An error occurred at the motor
drive circuit in the main PCB.
0102 2-42
Print Unable 02 Turn the power off and
then back on again.
Main PCB detected an error in the
paper feed motor.
0201 2-42
Main PCB detected an error in the
eject motor.
0203 2-42
Print Unable 03 Turn the power off and
then back on again.
Main PCB detected an error at the
polygon motor in the laser unit.
0300 2-43
Print Unable 04 Turn the power off and
then back on again.
Main PCB detected an error at the
polygon motor in the laser unit.
0401 2-43
Print Unable 05 Turn the power off and
then back on again.
Detected the fuser unit
temperature error.
0501 2-44
0502 2-44
0503 2-44
0504 2-44
0505 2-44
0506 2-44
0508 2-44
050A 2-45
050B 2-45
050C 2-45
Error message
Description
Error
codes
Refer
to:
First line Second line
