Brother HL-5590DN Service Manual

2-67
Confidential
 Error code 7B01
The MX jam lower sensor does not detect paper pass within the specified time after the eject
sensor detected paper pass.
 Error code 7B02
The MX 1bin stack sensor does not detect paper pass within the specified time after the MX
jam lower sensor detected paper pass.
<User Check>
• Remove the jammed paper.
• Close the back cover correctly.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2 MX flapper attachment failure Reattach the MX flapper.
3
Connection failure of the MX
jam lower sensor harness
Reconnect the MX jam lower sensor harness.
4
Connection failure of the MX
motor harness
Reconnect the MX motor harness.
5 MX switching solenoid failure Replace the MX switching solenoid.
6 MX motor failure Replace the MX motor.
7 MX control PCB failure Replace the MX control PCB ASSY.
8 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Remove the jammed paper.
• Close the MX back cover correctly.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2 MX flapper 1 attachment failure Reattach the MX flapper 1.
3
MX 1bin stack actuator
attachment failure
Reattach the MX 1bin stack actuator.
4
Connection failure of the MX
flapper 1 solenoid harness
Reconnect the MX flapper 1 solenoid harness.
5
Connection failure of the MX
1bin stack sensor harness
Reconnect the MX 1bin stack sensor harness.
6
Connection failure of the MX
relay PCB harness
Reconnect the MX relay PCB harness.
7 MX 1bin stack sensor failure Replace the MX 1bin stack sensor.
8 MX flapper 1 solenoid failure Replace the MX flapper 1 solenoid.
9 MX relay PCB failure Replace the MX relay PCB ASSY.
10 MX control PCB failure Replace the MX control PCB ASSY.
11 Main PCB failure Replace the main PCB ASSY.
