2-68
Confidential
Error code 7B03
The MX 2bin stack sensor does not detect paper pass within the specified time after the MX
jam lower sensor detected paper pass.
<User Check>
• Remove the jammed paper.
• Close the MX back cover correctly.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2
MX flapper 1 or 2 attachment
failure
Reattach the MX flapper 1 or 2.
3
MX 2bin stack actuator
attachment failure
Reattach the MX 2bin stack actuator.
4
Connection failure of the MX
flapper 2 solenoid harness
Reconnect the MX flapper 2 solenoid harness.
5
Connection failure of the MX
2bin stack sensor harness
Reconnect the MX 2bin stack sensor harness.
6
Connection failure of the MX
relay PCB harness
Reconnect the MX relay PCB harness.
7 MX 2bin stack sensor failure Replace the MX 2bin stack sensor.
8
MX flapper 1 or 2 solenoid
failure
Replace the MX flapper 1 or 2 solenoid.
9 MX relay PCB failure Replace the MX relay PCB ASSY.
10 MX control PCB failure Replace the MX control PCB ASSY.
11 Main PCB failure Replace the main PCB ASSY.
To Next Page
