2-69
Confidential
Error code 7B04
The MX 3bin stack sensor does not detect paper pass within the specified time after the MX
jam upper sensor detected paper pass.
<User Check>
• Remove the jammed paper.
• Close the MX back cover correctly.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2 MX flapper 3 attachment failure Reattach the MX flapper 3.
3
MX 3bin stack actuator
attachment failure
Reattach the MX 3bin stack actuator.
4
Connection failure of the MX
flapper 3 solenoid harness
Reconnect the MX flapper 3 solenoid harness.
5
Connection failure of the MX
3bin stack sensor harness
Reconnect the MX 3bin stack sensor harness.
6
Connection failure of the MX
relay PCB harness
Reconnect the MX relay PCB harness.
7 MX 3bin stack sensor failure Replace the MX 3bin stack sensor.
8 MX flapper 3 solenoid failure Replace the MX flapper 3 solenoid.
9 MX relay PCB failure Replace the MX relay PCB ASSY.
10 MX control PCB failure Replace the MX control PCB ASSY.
11 Main PCB failure Replace the main PCB ASSY.
To Next Page
