Brother MFC-9330CDW Service Manual

2-28
Confidential
Replace
Toner
Open the Top
Cover, replace
Toner Cartridge.
Dot counter of the toner
cartridge or develop roller counter
has reached the upper limit was
detected.
4C01
4C02
4C03
4C04
4C05
2-46
Replace WT
Box
Replace the Waste
Toner Box inside
the machine. To
get to it, remove all
the Drums &
Toners then remove
the Belt Unit.
After the waste toner sensor
detected that the waste toner box
was almost full, pages more than
the specified number have been
printed.
4800 2-44
Scanner
Error
-
Some error was detected while
function code 55 was being
executed.
B700
B800
B900
BB00
BD00
2-75
Self-
Diagnostic
Will Automatically
Restart within 15
minutes.
After the error was detected at the
fuser unit, power was turned ON
again and the error is being
checked.
6902 2-54
Short paper Open the Back
Cover and then
press Start
The registration rear sensor
detected that the paper loaded in
the paper tray was smaller than the
specified size.
8D01 2-63
Size Error
2-sided
Specify the
correct paper
The registration rear sensor
detected that the fed paper was
larger or smaller than the
specified size in 2-sided printing.
8A01 2-62
Press Stop Key.
Specify the
correct paper and
load the same size
paper as the Printer
driver setting.
For 2-sided printing, the tray whose
paper size was not supported by
2-sided printing was selected.
9701 2-66
Size
Mismatch
Reload correct
paper in Tray1,
then press Start.
The size of paper loaded in the
paper tray and the one specified
from the driver are not same when
paper is fed from the paper tray.
9002 2-64
Reload correct
paper.
Some paper size error occurred
while fax, list, or report was being
printed.
8E01
8E02
8E03
2-63
2-64
Small paper Open the Back
Cover and then
press Start
When printing with the back cover
closed, the paper size selected in
the print data is smaller than the
valid size.
8D02 2-63
Error message
Description
Error
codes
Refer
to:
Upper line Lower line

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
