5.3 Cassette Pickup Assembly
5.3.1 Outline
The machine’s pickup assembly is constructed as shown in T02-503-01 and F02-503-01.
The paper inside the cassette is moved up by the work of a lifter, and remains in contact
with the pickup roller.
When the pickup roller clutch turns on, the pickup roller starts to rotate to pick up paper.
Then, the pickup roller releasing solenoid turns on so that the pickup roller moves away
from the surface of the stack of paper.
The feed roller and the separation roller make sure that only one sheet of paper is for-
warded to the feed path, in which the paper is moved by the pickup vertical path to the
transfer belt by way of the registration roller.
Item Description
Feed reference Center
Paper stack Cassette 1/2: 550 sheets each (of 81.4 g/m
2
paper)
Paper size switch Universal cassette (by user)
Related mechanical adjustments Cassette horizontal registration
T02-503-01
