CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-101
3.4.18 The copy has color displacement.
1) Set ‘FUNC > IMG-REG > AUTO-ADJ’ in service mode to ‘ON’. Is
the problem corrected?
YES: End.
Transfer belt
2) Does the transfer belt have dents or deformation?
YES: Replace it.
Retention
3) Does the C transfer blade have dents or deformation?
YES: Replace it.
4) Is the operation of the locking mechanism of the C transfer blade
normal?
NO: Remove the cause of the fault.
Drum drive system
5) Is the gear of the photosensitive drum worn or loose?
YES: Replace the gear.
6) Does the flywheel wobble?
YES: Tighten the mounting screw.
7) Clean the ends of the photosensitive drum and the spacer rubber. Is
the problem corrected?
YES: End.
NO: Check the developing drive system for wobbling and other faults.
To Next Page
