CANON CLC5000 REV.0 JAN. 2001
CHAPTER 3 INSTALLATION
3-4
2 Points to Note for Installation and Relocation
2.1 Base Plate and Installation/Relocation Work
When moving the machine while supporting its base plate, be sure to place your hands as
shown; otherwise, the external covers can suffer deformation.
F03-201-01
left sideright side
front back frontback
