8 Paper Deck-J1/K1
8.1 Outline
The Paper Deck-J1 differs from the Paper Deck-H1 for the following two points:
• Elimination of the pickup cutch (CL8001)
The rest are the same as those of the Paper Deck-H1.
In addition to the above, the Paper Deck-K1 is different from the paper deck designed for the
CLC1000 for the following:
• Addition of a deck sensor (PS8003)
The following paper sizes may be used for the Paper Deck-J1/K1:
Paper Deck-J1 (2000 sheets) Paper Deck-K1 (4000 sheets)
Supported paper sizes A3 extra-length (305x457 mm), A3, A4, B5, LTR
(81.4 g/m
2
) A4, B4, B5, LTR, 11x17 (279x432 mm)
T02-801-01
REF.
If you are installing a CLC1000 Paper Deck/Paper Deck-H1 to a CLC5000
Series machine, be sure to use the upgrade kit.
8.2 Differences in the Paper Deck-J1/K1
Unit/Location Differences from Paper Deck-H1 Remarks
(CLC1000 paper deck)
Deck pickup assembly Elimination of the pickup clutch To obtain drive from
(CL8001) the deck motor (M36)
Addition of a deck sensor of the host
(PS8003) : Paper deck-k1 only
T02-802-01
