CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-72
3.3.2 256-Color Test Print (PGTYPE=02)
Use the 256-color test print to check the hues.
For the 256-color test print, the 16×16 frames from the leading edge of the copy paper
represent 256 colors; all frames that follow are repetitions of the first set.
a.Hues of the 256 Colors
The print must show the hues shown in F05-303-01.
If the hues are different, suspect deterioration of the developer, deterioration of the photo-
sensitive drum, and mixing of developers.
F05-303-01
16 frames
16 frames
