Canon CLC5000 - E005; E006

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-109
4.1.2 E005
Cleaning web
1) Is the cleaning web more or less used up?
YES: Replace the cleaning web.
Counter
2) After replacing the cleaning web, has ‘FUNC > FUSER > E005-
RLS’ in service mode been executed?
NO: Execute ‘FUNC > FUSER > E005-RLS’ in service mode.
Detecting lever (position)
3) Is the detecting lever of the web length sensor on the web?
NO: Re-mount it.
Web length sensor (PS36)
DC controller PCB
4) Is the web length sensor (PS36) normal?
NO: Replace the web length sensor.
YES: Replace the DC controller PCB.
You cannot clear ‘E005’ by executing ‘E005-RLS’ without replacing the
web. Replace the web first.
4.1.3 E006
Fixing drawer connector
DC controller PCB
1) Is there a fault in the fixing drawer connector?
YES: Replace the drawer connector.
NO: Check the wiring from J22098A on the DC controller PCB to the
fixing drawer connector J601; if normal, replace the DC controller
PCB.
