3.5 Disassembly/Assembly
The machine has the mechanical features and operations as described herein, and may be
disassembled or assembled as shown; be sure to observe the following whenever disassem-
bling or assembling the machine:
1.
Disconnect the power plug for safety before the work.
2. Unless otherwise noted, reverse the steps used to disassemble the machine for assembly.
3. Identify the screws by type (length, diameter) and location.
4. The screws used for the grounding wire, varistors, or the like are equipped with washers
to ensure electrical continuity. Be sure to use these screws during assembly.
5. As a rule, do not operate the machine with any of its parts removed.
6. Be sure to turn off the front cover switch or the power switch before sliding out the du-
plex unit or the fixing/feeding unit.
7. Do not throw toner into fire to avoid explosion.
8. For the following items, refer to CLC1000 series service manual.
• Disassembly of the laser unit
• Disassembly of the dust proof glass
• Disassembly of the BD unit
