Canon CLC5000 - Basic Sequence of Operations; Timing Chart (Fixing;Delivery Assembly)

2-131
CHAPTER 2 NEW FUNCTIONS
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
CNTR
COPY LSTR
STBYSTBY
165˚C
WMUP
INTR
182˚C
182˚C
175˚C
165˚C
204mm/s
202mm/s
204mm/s
A4/LTR, 2 Copies, 4-Color, Direct, Cassette 1, Plain paper
Photosensitive drum
motor (M21)
Pre-fixing feed
motor (M11)
Fixing motor (M9)
Fixing web
releasing solenoid
(SL4)
Fixing take-up
solenoid (SL3)
Fixing web
motor (M30)
Separation claw
releasing solenoid
(SL15)
Upper fixing heater
(H1)
Lower fixing heater
(H2)
Power switch ON
Start key ON
Controlled
to 180 ˚C
Controlled
to 180 ˚C
Controlled
to 175 ˚C
Controlled
to 175 ˚C
Web released
202 mm/s (standard)
ON for each
8 sheets
Separation claw
released
6.8 Timing Chart (fixing/delivery assembly)
6.8.1 Basic Sequence of Operations
F02-608-01
