Canon CLC5000 - ED Board A1

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-205
6.8.15 ED board A1
F05-608-17
LED Function
LED1: ON while +3.3 V power is being supplied.
LED2: ON while +5 V power is being supplied.
T05-608-11
LED2 LED1
114
1
2
41
42
39
40
79
80
J1501
J1504
122
121
2
1
J1502
40
39
80
79
1
2
42
41
J1503
