4.1.32 E350
Connector
1) Is the connection between the reader controller PCB and the ECO-
ID PCB normal?
NO: Connect the PCBs correctly.
ECO-PCB
Reader controller PCB
2) Replace the ECO-ID PCB. Is the problem corrected?
YES: End.
NO: Replace the reader controller PCB.
4.1.33 E351
Connector
1) Is the connection between the analog processor PCB and the image
processor PCB normal?
NO: Connect the PCBs correctly.
2) Is the connection between the reader contoroller PCB and the im-
age processor PCB normal?
NO: Connect the PCBs correctly.
3) Try replacing the image processor PCB. Is the problem corrected?
YES: End.
NO: Replace the analog processor PCB or the reader controller PCB.
