COPYRIGHT
©
2001 CANON INC.
2000 2000 2000 2000
CANON CLC5000 REV.0 JAN. 2001
CHAPTER 3 INSTALLATION
3-38
belt retaining members
Developing bias assembly
protection member
8 Using the Crane Transport kit
If you are using the transport kit to move the machine by suspending it on a crane, per-
form the following:
8.1 Items to Prepare
Crane Transport Kit (FG6-1585-000)
Contents • Belt retaining member 4pc.
• Developing bias assembly protection member 1pc.
F03-801-01
