Canon CLC5000 - When Replacing the Developing Assembly (CMYK)

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-28
■ Replacement for C/M/Y
32) Execute ‘STIR-C/M/Y’ as necessary.
(about 1 min)
33) Execute ‘INIT-C/M/Y’ as necessary.
(about 1 min)
34) Execute ‘SINIT-C/M/Y’ as necessary.
(about 1 min)
35) Execute ‘WINCLR-C, M, or -Y’.
36) Select ‘1’ by executing ‘ADJUST >
PASCAL > PASCAL’.
37) Record the result on the service label.
38) Turn off and then on the power switch.
39) Execute ‘auto gradation correction (full
correction)’ in user mode.
■ Replacement for Bk Only
32) Execute ‘STIR-K’. (about 1 min)
33) Execute ‘SINIT-K’. (about 1 min)
34) Execute ‘WINCLR-K’.
35) Record the result on service mode.
36) Select ‘1’ by executing ‘ADJSUT >
PASCAL > PASCAL’.
37) Turn off and then on the power switch.
38) Execute ‘auto gradation correction (full
correction)’ in user mode.
2.5.2 When Replacing the Developing Assembly (CMYK)
1) Using ‘FUNC > INSTALL’ in service
mode, set ‘IMNG-REG’ to ‘0’.
2) Replace the developing assembly.
3) Replace the developer of the color in
guestion.
4) Using ‘FUNC > INSTALL’ in service
mode, set ‘IMG-REG’ to ‘1’.
