2-196
CHAPTER 2 NEW FUNCTIONS
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
k. Removing the Hater Triac (upper, lower)
1) Remove the rear cover (3).
2) Remove the two screws [1], and detach
the heat triac (upper) [2].
Note:
The heater triac (lower) [3] may be
removed in the same way.
[1]
[1]
[2]
[3]
F02-706-77
