1-15
CHAPTER 1 GENERAL DESCRIPTION
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
[1] External delivery roller
[2] Internal delivery roller
[3] No. 2 mirror base
[4] Fixing upper belt
[5] Scanning lamp
[6] Fixing upper roller
[7] Oil applying roller
[8] Fixing lower roller
[9] Pre-fixing feeding assembly
[10] Separation charging assembly
[11] Image position correction CCD unit
[12] Lens
[13] K BD sensor
[14] CCD
[15] K image position correction mirror
[16] K No. 3 mirror
[17] Y image position correction mirror
[18] Y BD sensor
[19] Y No. 3 mirror
[20] Internal static eliminating roller
[21] Polygon mirror/motor
[22] M No. 3 mirror
[23] M BD sensor
[24] M image position correction mirror
[25] C No. 3 mirror
[26] C image position correction mirror
[27] C BD sensor
[28] Registration roller
[29] Paper thickness detection roller
[30] Multifeeder feed roller
[31] Multifeeder pickup roller
[32] Multifeeder tray
[33] Delivery vertical path roller
[34] Duplex reversal inlet roller
[35] Fixing lower roller web
[36] Duplex reversal feed roller
[37] Duplex reversal outlet roller
[38] Waste toner box
[39] Transfer cleaning blade
[40] Pre-duplex feeding assembly
[41] Transfer belt
[42] Transfer belt cleaning web
[43] Cassette 2
[44] Duplex unit
[45] Oil removing roller
[46] Polishing roller
[47] Cassette 1
[48] Pickup roller
[49] Feed roller
[50] Separation roller
[51] Pickup vertical path roller
[52] Paper deck separation roller
[53] Paper deck feed roller
[54] Paper deck pickup roller
[55] Pre-exposure roller
[56] Pre-primary charging assembly
[57] Photosensitive drum cleaner
[58] SALT sensor
[59] Primary charging assembly
[60] Potential sensor
[61] Developing assembly
[62] Photosensitive drum
[63] Transfer blade
[64] Feeding roller
[65] Pre-fixing charging assembly
