CHAPTER 4 MAINTENANCE AND SERVICING
4-1
1 Periodically Replaced Parts
As of Dec 2000
No.
1
2
3
4
5
6
7
8
9
10
11
Parts name
Ozone filter 1
(primary charging assembly)
Ozone filter 2
(delivery assembly, general
exhaust)
Ozone filter 3
(power supply assembly, pre-
fixing exhaust)
Ozone filter 4
(reversing assembly exhaust)
Dust-proofing filter 1 (laser
unit, cooling, primary charg-
ing assembly, pre-fixing ex-
haust filter)
Dust-proofing filter 3
(digital unit suction filter)
Dust-proofing filter 4
(primary suction filter)
Dust-proofing filter 6
(delivery assembly, general
exhaust)
Dust-proofing filter 7
(Laser scanner cooling)
Toner filter
(primary charging assembly)
Pre-fixing duct filter
(Pre-fixing duct)
Parts number
FB2-3702-000
FB5-8775-000
FB2-3704-000
FB5-8428-000
FA6-4538-000
FB2-3955-000
FB3-5608-020
FB3-6320-020
FB5-6264-000
FB2-4383-000
FF6-1117-000
Q’ty
1
2
4
1
7
3
2
2
1
1
1
Life
100,000
100,000
100,000
100,000
100,000
100,000
100,000
100,000
100,000
100,000
50,000
Remarks
Or 1 yr. (FM6: primary
charging assembly fan)
Or 1 yr. (FM1/2/3: delivery
assembly exhaust fan FM21/
22/23: general exhaust)
Or 1 yr. (FM17/18: power
supply assembly exhaust
fan; FM35/36: pre-fixing
exhaust fan)
Or 1 yr. (FM28/29/30/33:
reversing assembly exhaust
fan)
Or 1 yr. (FM4/5/6/17/18/
35/36)
Or 1 yr. (FM14/15/16:
digital unit cooling fan)
Or 1 yr. (FM8/9: primary
charging assembly suction
fan)
Or 1 yr. (FM1/2/3: delivery
assembly exhaust fan; FM21/
22/23: general exhaust)
Or 1 yr. (FM24: laser scan-
ner motor cooling fan)
Or 1 yr. (FM6: primary ex-
haust fan)
Or 1 yr. (FM35/36: pre-
fixing exhaust fan)
Memo
The above values are estimates only and are subject to change based on fu-
ture data.
The parts numbers are subject to change according to engineering revisions.
T04-100-01
