COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN 2001
CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-103
3.4.20 Adjusting the Image Leading
Laser write start position
transfer high voltage application timing
1) Generate a test print (PGTYPE-10). Is the image normal?
YES: Go to step 3.
Original read start position
2) Adjust the setting in service mode, i.e., use a lower setting:
‘ADJUST>FEED-ADJ>VSYC-ADJ’. Is the problem corrected?
YES: End.
3) Execute image read position adjustment (ADJ-Y). (Refer to 2.1.3.c
“Adjusting the Image Red Position” in this chapter.)
