CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-107
d.E000–0061, 0071, 0081
1) Clear ‘E000’. Is ‘E000’ indicated immediately after the power
switch is turned on?
• Be sure to turn off the power switch as soon as you have made the
check.
NO: Go to step 3.
Oil thermistor (TH5), Oil heater thermistor (TH6; short circuit), DC controller PCB
2) Turn off the power switch, and disconnect J6019 from J2209 on the
DC controller PCB. Measure the resistance between a and b of the
following table in reference to the detail code; is it 1 K
ΩΩ
ΩΩ
Ω?
Code a b
0061/0081 J6019-B5 J6019-B6
0071/0081 J6019-B10 J6019-B11
AC driver PCB
DC controller PCB
3) Replace the AC driver PCB. Is the problem corrected?
YES: End.
NO: Replace the DC controller PCB.
To Next Page
