CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-150
Test button
System of checking the Leakage Breaker
1. Press the test button of the breaker.
F05-401-14
2. Check to make sure that open/close lever has shifted to the OFF
terminal side and the power has been cut.
F05-401-15
3. Turn off the power switch.
4. Shift the open/close lever to the ON side.
F05-401-16
5. Turn on the power switch.
To Next Page
