CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-198
■ For Y/M
F05-608-09
VR Function
VR3001: Use it to set the laser power minimum level (at time of replacing the laser unit).
VR3002: Use it to set the laser power maximum level (at time of replacing the laser unit).
VR3003:
VR3004:
VR3005:
VR3006 : Use it to adjust the laser power or the laser intensity (at time of replacing
VR3007: the laser unit).
VR3008:
VR3009:
VR3010: for factory adjustment (Do not touch.)
T05-608-04
VR3007VR3009
VR3004
VR3002
VR3006
VR3010
VR3005
VR3003
VR3008
VR3001
J3002
25
1
J3001
25
1
