COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-203
■ HVT2-2
F05-608-14
LED Function
LED4603: ON while (Y) Pre-primary charging high voltage is being generated.
LED4604: ON while (Y) primary charging high voltage is being generated
T05-608-09
8
J4602
1
3
J4604
1
1
W4601-2
8
AUX P
LED4604
LED4603
J4606
