SERVICE MODE
S-33
T-POS
Indicates the position of the tray. 0: Home position
State 1: Increases by 1
L-MOVE
Indicates that the lens is moving.
State 1: Moving
M-EXCT
Indicates the state of motor excitation.
State 1: Excited
L-POS
Indicates the position of the lens.
State 0: Home position
LAMP-ERR
Indicates an open circuit in the lamp.
State 1: Open circuit
INITIAL
Indicates that initialization is under way.
State 1: Processing
LOCAL
Indicates local movement.
State 1: Operating
R/L
Indicates remote/local mode.
State 0: Remote
1: Local
