SERVICE MODE
S-35
<SORT-INF (SORT state)>
DISP
ADJUST
COUNTER
FUNC
OPTION
TEST
ERROR JAM
READY READY USER
SORT-INF
xxxx
xx
ALARM-1 ALARM-2 ALARM-3 ALARM-4
xx
xx
xx xx
STATUS-1 STATUS-2 STATUS-3 STATUS-4
xx
xx
xx xx
F00-200-16
STATUS-1/2/3/4
For R&D
ERROR
For R&D
JAM
Indicates the jam code sent by the sorter controller PCB.
03H:feeding delay jam
02H:feeding stationary jam
03H:staple jam
04H:power-on jam
08H:cover open jam (during feeding)
09H:cover open jam (other than during feeding)
ALARM-1/2/3/4
Indicates the alarm code sent by the sorter controller PCB.
ALARM-1
02H:overstacking
ALARM-2
02H:staple jam
03H:stapler safety mechanism activation
04H:stapler overstacking
05H:mixed paper sizes (horizontal)
07H:stapler unit absent
08H:separation failure
0AH:staple absent
ALARM-3/4
for future use
