SERVICE MODE
S-37
BST
Indicates the time required by the transfer belt between when it reaches the
transfer belt edge sensor 1 (PS18, rear) and when it leaves the sensor.
BST XXXX XXXX XXXX
Most recent data
Second most recent data
Third most recent data
State Unit: 0.1 sec
B TO F
Indicates the time required by the transfer belt between when it reaches the
transfer belt edge sensor 2 (PS18, rear) and when it reaches the end sensor
1 (PS17, front).
B TO F
XXXX XXXX XXXX
Most recent data
Second most recent data
Third most recent data
State Unit: 0.1 sec
F TO B C.Time
Indicates data (F TO B data minus FST data); time taken by the belt to
move from front to back.
F TO B C. Time
XXXX XXXX
second most recent
third most recent
State Unit: 0.1 sec
B TO F C.Time
Indicates data (B TO F data minus BST data); time taken by the belt to
move from back to front.
B TO F C. Time XXXX XXXX
second most recent
third most recent
State Unit: 0.1 sec
TOTAL
indicates data (F TO B data plus B TO F data); time taken by the belt to
make a round trip.
State Unit: 0.1 sec
