SERVICE MODE
S-40
<ADJ-XY (image read start position adjustment)>
F00-300-02
<M> <S> <R> <P> <F>
DISP
ADJUST
FUNC
COUNTER ADJ-X
OPTION
TEST
xxxx
ADJ-Y
xxxx
ADJ-S
xxxx
ADJ-J
xxxx
ADJ-XY READY READY
ADJ-X
*1
Use it to make adjustments so that the image read start position (X direc-
tion, sub scanning direction) matches the reference point on the copyboard
glass.
Fine-adjusts the distance from the original scanner home position sensor to
the read start position.
Unit: Number of steps of the stepping motor.
• Follow the instructions on the next page.
Settings range 0~+400
(–3.9~+3.9mm)
Unit: 0.11 mm (approx.)
ADJ-Y
*1
Use it to make adjustments so that the image read start position (Y direc-
tion, main scanning direction) matches the reference point on the copyboard
glass.
Unit: Pixel
• Follow the instructions on the next page.
Settings range –100~+100
(–2.5~+2.5mm)
Unit: 0.06mm (approx.)
