SERVICE MODE
S-45
<PROJ (projector area adjustment)>
<M> <S> <R> <P> <F>
DISP
FUNC
COUNTER
OPTION
TEST
xxxx
ADJUST
PJRD-XS
xxxx
PJDA-XS
xxxx
PJRD-XE
xxxx
PJDA-XE
xxxx
PJCAR-X
xxxx
PJCAR-Y
xxxx
PJRD-YS
xxxx
PJDA-YS
xxxx
PJRD-YE
xxxx
PJDA-YE
PROJ READY READY
F00-300-07
YE
YS
XEXS
On copyboard
glass
+
–
+
–
+
–
+
–
YS
YE
XE XS
On
copy
+
–
+
–
+
–
+
–
PJRD-XS/-XE/-YS/-YE
Fine-adjusts the read area if original detection mechanism is off with the
projector in use or if original detection fails when the original detection
mechanism is on.
F00-300-08
Settings range –300~+300
(–19.0~+19.0mm)
Standard=0
For XS/XE,
Unit: 0.11 mm (approx.)
For YS/YE,
Unit: 0.06 mm (approx.)
