SERVICE MODE
S-113
No.
31
32
33
34
35
36
Motor
M38(cassette1 pickup motor)
M39(cassette2 pickup motor)
M37(re-pickup motor)
M36(paper deck pickup motor)
M35(registration motor)
M2(buffer unit reversal motor)
Control
Operates for 10sec,stops for 3sec,and then
operates for 10 sec and stops
Operates for 10sec,stops for 3sec,and then
operates for 10 sec and stops
Operates for 10sec,stops for 3sec,and then
operates for 10 sec and stops
Operates for 10sec,stops for 3sec,and then
operates for 10 sec and stops
Operates for 10sec,stops for 3sec,and then
operates for 10 sec and stops
Operates for 10sec,stops for 3sec,and then
operates for 10 sec and stops
To Next Page
