Canon E1 - Removing the Deck Pull-Out Motor (M104;204;304)

3. Remove the Deck Pickup Motor [1].
• 2 Screws [2]
• 1 Timing Belt [3]
2x
[1]
[2]
[2]
[3]
Removing the Deck Pull-out Motor (M104/204/304)
■ Preparation
1. Remove the Deck Rear Upper Cover.“Removing the Deck Rear Upper Cover” on page 79
2. Remove the Deck Rear Middle Cover.“Removing the Deck Rear Middle Cover” on page 79
3. Remove the Deck Rear Lower Cover.“Removing the Deck Rear Lower Cover” on page 79
4. Remove the Deck Left Rear Cover.“Removing the Deck Left Rear Cover” on page 80
■ Procedure
NOTE:
The removal procedure of the Deck Pull-out Motor from the Middle Deck is described below. The procedure of the Upper and
Lower Decks is the same.
1. Remove the Cable Guide [1] with the cable.
• 2 Connectors [2]
• 3 Hooks [3]
[1]
[2]
[2]
[3]
2x
