Canon E1 - Switches

Switches
SW001
SW002
SW102
SW202
SW302
SW408
No. Part Name Main Unit Reference
SW001 Deck Left Front Cover Safety Switch - -
SW002 Cassette Heater Switch - -
SW102 Upper Deck Lifter Lower Limit Switch Upper Deck -
SW202 Middle Deck Lifter Lower Limit Switch Middle Deck -
SW302 Lower Deck Lifter Lower Limit Switch Lower Deck -
SW408 Through Path Safety Switch Through Path Unit -
4. Parts Replacement and Cleaning
68
