Items
Service Mode
(COPIER> OPTION)
Use case Remarks
Setting the area-specific
standard size paper cat-
egory 1 used in Middle
Deck
CST> CST6-U1
CST> CST9-U1 *
When setting area-specific standard size
paper
Setting the area-specific
standard size paper cat-
egory 3 used in Middle
Deck
CST> CST6-U3
CST> CST9-U3 *
When setting area-specific standard size
paper
Setting the area-specific
standard size paper cat-
egory 1 used in Lower
Deck
CST> CST7-U1
CST> CST10-U1 *
When setting area-specific standard size
paper
Setting the area-specific
standard size paper cat-
egory 3 used in Lower
Deck
CST> CST7-U3
CST> CST10-U3 *
When setting area-specific standard size
paper
Entry of the Serial Num-
ber: M-Paper Deck
SERIAL> PDECK1
SERIAL> PDECK2 *
- At installation
- When replacing the Deck Controller PCB
Setting of Multi Deck (Up-
per) Air Heater
USER> DK2-ASST
USER> DK5-ASST *
Upon user's request (to shorten the waiting
time)
Be sure to get approval from
the user in advance by ex-
plaining that there is a possi-
bility that transfer perform-
ance may decrease in a low
humidity environment when 2
is set.
Setting of Multi Deck
(Middle) Air Heater
USER> DK3-ASST
USER> DK6-ASST *
Upon user's request (to shorten the waiting
time)
Be sure to get approval from
the user in advance by ex-
plaining that there is a possi-
bility that transfer perform-
ance may decrease in a low
humidity environment when 2
is set.
Setting of Multi Deck
(Lower) Air Heater
USER> DK4-ASST
USER> DK7-ASST *
Upon user's request (to shorten the waiting
time)
Be sure to get approval from
the user in advance by ex-
plaining that there is a possi-
bility that transfer perform-
ance may decrease in a low
humidity environment when 2
is set.
Setting the Upper Deck
Air Float Fan OFF timing
USER> DK2-BSTP
USER> DK5-BSTP *
When uneven transfer occurs due to
change in moisture content
Setting the Middle Deck
Air Float Fan OFF timing
USER> DK3-BSTP
USER> DK6-BSTP *
When uneven transfer occurs due to
change in moisture content
Setting the Lower Deck
Air Float Fan OFF timing
USER> DK4-BSTP
USER> DK7-BSTP *
When uneven transfer occurs due to
change in moisture content
Actions when Replacing the Parts
No Parts Contents Reference
1 Deck Front Cover Adjusting the position of the Deck Front Cover “Adjusting the Deck Front Cover Gap” on
page 173
2 Deck Controller PCB Backup of each adjustment value before the ex-
change, and write of backup data after the exchange
“Actions when Replacing the Deck Con-
troller PCB (PCB001)” on page 174
3 Deck Size Detection PCB Adjusting the paper width “Actions when Replacing the Deck Size
Detection PCB (PCB101/201/301)” on
page 175
