■ Actions when Replacing the Parts
1. Clear the parts counter in the following service mode.
COPIER > COUNTER > DRBL-2 > MD-FD-R1/R2/R3 (M Deck Upper/Middle/Lower)
COPIER > COUNTER > DRBL-2 > MD2-FDR1/R2/R3 (Sec M Deck Upper/Middle/Lower)
Removing the Deck Separation Roller
■ Preparation
1. Release the lock to open the target Deck. “Releasing the Deck” on page 77
■ Procedure
NOTE:
The removal procedure of the Deck Separation Roller from the upper deck is described below. The procedure of the middle and
lower decks is the same.
CAUTION:
Be sure not to touch the surface of the roller at disassembling/assembling.
4. Parts Replacement and Cleaning
104
