Canon E1 - Removing the Deck Right Middle Cover

■ Procedure
1. Remove the Deck Upper Cover [1].
• 3 Screws [2] (to be loosened)
• 3 Screws [3] (to be removed)
[2]
[3]
[3]
3x
[1]
3x
Removing the Deck Right Middle Cover
■ Preparation
1. Release the lock to open the Middle Deck.“Releasing the Deck” on page 77
■ Procedure
1. Remove the Deck Right Middle Cover [1].
• 2 Screws [2]
2x
[1]
[2]
4. Parts Replacement and Cleaning
82
