Canon E1 - Power Supply

Jam Code Jam Types Sensor Sensor Name
2018 Delay jam PS1 Deck Pickup Sensor
2019 Delay jam PS2 Deck Pull-out Sensor
2104 Stationary jam S104 Deck Pull-out Sensor
2105 Stationary jam S204 Middle Deck Pull-out Sensor
2106 Stationary jam S304 Lower Deck Pull-out Sensor
2108 Stationary jam S002 Vertical Path Middle Sensor
2109 Stationary jam S003 Vertical Path Lower Sensor
2110 Stationary jam S004 Horizontal Path Sensor 1
2111 Stationary jam S005 Horizontal Path Sensor 2
2113 Stationary jam S401 Multi Tray Inlet Sensor
2115 Stationary jam S60 Through Path Outlet Sensor 1
2119 Stationary jam PS2 Deck Pull-out Sensor
2301 Power ON jam - -
2401 Door Open jam - -
2402 Deck Door Open jam - -
2701 Stationary jam - -
2801 Double Feed jam S501, S502 Upper Double Feeding Sensor
2802 Double Feed jam S503, S504 Lower Double Feeding Sensor
2803 Double Feed jam S420, S421 Through Path Double Feeding Sensor
2F01 Sequence Error jam - -
2F02 Error avoidance jam - Horizontal Path Disengagement Motor 1 Error (E505)
2F03 Error avoidance jam - Horizontal Path Disengagement Motor 2 Error (E505)
2F04 Error avoidance jam - Lower Path Disengagement Motor Error (E505)
2F05 Error avoidance jam - Front Alignment Plate Motor Error (E505)
2F06 Error avoidance jam - Rear Alignment Plate Motor Error (E505)
Power Supply
■ Power Supply
The DC power supply is provided for this equipment by the DC Power supply PCB.
The DC Power supply PCB generates and provides the DC power supply (+24V) for the Deck driver PCB.
2. Technology
41
