Canon E1 - Fans

No. Part Name Main Unit Reference
SOL102 Upper Deck Open/Close Solenoid - “Removing the Deck Open/Close Solenoid
(SOL102/202/302)” on page 119
SOL201 Middle Deck Pickup Solenoid Pickup Unit “Removing the Deck Pickup Solenoid
(SOL101/201/301)” on page 120
SOL202 Middle Deck Open/Close Solenoid - “Removing the Deck Open/Close Solenoid
(SOL102/202/302)” on page 119
SOL301 Lower Deck Pickup Solenoid Pickup Unit “Removing the Deck Pickup Solenoid
(SOL101/201/301)” on page 120
SOL302 Lower Deck Open/Close Solenoid - “Removing the Deck Open/Close Solenoid
(SOL102/202/302)” on page 119
Fans
FAN102
FAN202
FAN302
FAN101
FAN301
FAN201
FAN001
FAN002
FAN401
FAN402
No. Part Name Main Unit Reference
FAN001 Power Supply Cooling Fan 1 - “Removing the Power Supply Cooling Fan 1 (FAN001)” on
page 124
FAN002 Power Supply Cooling Fan 2 - “Removing the Power Supply Cooling Fan 2 (FAN002)” on
page 125
FAN101 Upper Deck Flotation Fan 1 Deck Unit “Removing the Deck Flotation Fan 1 (FAN101/201/301)” on
page 126
FAN102 Upper Deck Flotation Fan 2 Deck Unit “Removing the Deck Flotation Fan 2 (FAN102/202/302)” on
page 127
FAN201 Middle Deck Flotation Fan 1 Deck Unit “Removing the Deck Flotation Fan 1 (FAN101/201/301)” on
page 126
FAN202 Middle Deck Flotation Fan 2 Deck Unit “Removing the Deck Flotation Fan 2 (FAN102/202/302)” on
page 127
FAN301 Lower Deck Flotation Fan 1 Deck Unit “Removing the Deck Flotation Fan 1 (FAN101/201/301)” on
page 126
4. Parts Replacement and Cleaning
72
