Explanation of Basic Operations
Deck Open
Switch
Cassette Heater Switch
LED (Green) LED (Red)
Deck open switch
• Used to open the deck.
State of the LED
State of Operation presence/absence of pa-
per
LED(Green) LED(Red)
Under a wait Paper presence stays unlit stays unlit
Paper absence stays lit
Under a job
(The deck for paper feed)
Paper presence stays lit stays unlit
Paper absence stays unlit blinks
Under a job Paper presence stays unlit stays unlit
