Through Path Inlet Sensor
(S402)
Rear Alignment Plate
Front Alignment Plate
Paper
Jam Detection
■ Overview
This equipment has the sensors listed below to detect if the paper is correctly fed.
It reads the signal from the sensor at the check timing recorded in the host machine to judge whether there is jam or not.
If the host machine detects a jam, it delivers the sheets picked up before occurrence of the paper jam, and then stops the machine.
After stopping the machine, it displays the jam recovery procedure on the control panel.
2. Technology
39
