Canon E1 - Removing the Rear Alignment Plate Motor (M409)

2. Remove the Front Alignment Plate Motor [1].
• 1 Connector [2]
• 1 Spring [3]
• 2 Screws [4]
• 2 Stepped Screws [5]
• 1 Timing Belt [6]
4x
[1]
[2]
[3]
1x
[4]
[6]
[4]
[5]
[5]
Removing the Rear Alignment Plate Motor (M409)
■ Preparation
1. Remove the Right Connection Unit. “Removing the Right Connection Unit” on page 91
2. Remove the Deck Rear Middle Cover.“Removing the Deck Rear Middle Cover” on page 79
3. Remove the Through Path Unit.“Removing the Through Path Unit” on page 93
4. Remove the Through Path Outlet Unit.“Removing the Through Path Outlet Unit” on page 98
■ Procedure
1. Remove the Fixing Pin [1] and the Guide Plate [2].
• 3 Screws [3]
• 1 Hook [4]
3x
[2]
[1]
[3]
[3]
[3]
[4]
4. Parts Replacement and Cleaning
117
