Canon E1 - Removing the Horizontal Path Disengagement Motor 1 (M005)

7. Remove the Deck Swing Motor [1].
• 2 Screws [2]
2x
[1]
[2]
[2]
Removing the Horizontal Path Disengagement Motor 1 (M005)
■ Preparation
1. Remove the Deck Rear Upper Cover.“Removing the Deck Rear Upper Cover” on page 79
2. Remove the Deck Rear Middle Cover.“Removing the Deck Rear Middle Cover” on page 79
3. Remove the Deck Rear Lower Cover.“Removing the Deck Rear Lower Cover” on page 79
4. Remove the Deck Left Rear Cover.“Removing the Deck Left Rear Cover” on page 80
■ Procedure
1. Remove the Disengagement Motor Unit [1].
• 4 Connectors [2]
• 1 Wire Saddle [3]
• 2 Reuse Bands [4]
• 2 Screws [5]
[1]
[2]
[2]
[2]
[5]
2x
3x
4x
[5]
[2]
[3]
[4]
[4]
