Overview
Service Mode
In service mode, this equipment can perform the following adjustment, operation and inspection, and functional setting items.
■ Adjustment Items
*: For Secondary Multi-drawer Paper Deck
Items
Service Mode
(COPIER> ADJUST)
Use case Remarks
Adjustment of A4 paper
width (Upper)
CST-ADJ> MDK1-A4
CST-ADJ> MDK4-A4 *
- When replacing the Deck Controller PCB/
clearing RAM data.
- When registering a new value.
Adjustment of A5R paper
width (Upper)
CST-ADJ> MDK1-A5R
CST-ADJ> MDK4-A5R *
- When replacing the Deck Controller PCB/
clearing RAM data.
- When registering a new value.
Adjustment of A4 paper
width (Middle)
CST-ADJ> MDK2-A4
CST-ADJ> MDK5-A4 *
- When replacing the Deck Controller PCB/
clearing RAM data.
- When registering a new value.
Adjustment of A5R paper
width (Middle)
CST-ADJ> MDK2-A5R
CST-ADJ> MDK5-A5R *
- When replacing the Deck Controller PCB/
clearing RAM data.
- When registering a new value.
Adjustment of A4 paper
width (Lower)
CST-ADJ> MDK3-A4
CST-ADJ> MDK6-A4 *
- When replacing the Deck Controller PCB/
clearing RAM data.
- When registering a new value.
Adjustment of A5R paper
width (Lower)
CST-ADJ> MDK3-A5R
CST-ADJ> MDK6-A5R *
- When replacing the Deck Controller PCB/
clearing RAM data.
- When registering a new value.
Adjusting the arch
amount before registra-
tion for the 1st side of pa-
per
FEED-ADJ> LP-MDK When skew occurs on the 1st side at the
time of picking up paper from Multi Deck.
If the value is too large, paper
wrinkles or paper bending
may occur.
Adjusting the alignment
width of the Through Path
Unit
FEED-ADJ> MD-ALG - When installing the Through Path Unit to
the Multi Deck.
- When replacing the Deck Controller PCB
of the Multi Deck.
- When the image is tilted or out of align-
ment When using the Through Path Unit of
the Multi Deck.
If the value is small, a feeding
failure may occur.
Adjusting the center ref-
erence position of the
Multi Deck alignment
FEED-ADJ> MD-CENT - When installing the Through Path Unit to
the Multi Deck.
- When replacing the Deck Controller PCB
of the Multi Deck.
- When the center standard position of the
Through Path Unit is misaligned.
Adjusting for up the Feed
Belt pressure of the
Through Path Unit
FEED-ADJ> MD-ALG-R - When installing the Through Path Unit to
the Multi Deck.
- When replacing the Deck Controller PCB
of the Multi Deck.
Adjusting for down the
Feed Belt pressure of the
Through Path Unit
FEED-ADJ> MD-ALG-F - When installing the Through Path Unit to
the Multi Deck.
- When replacing the Deck Controller PCB
of the Multi Deck.
Adjusting the arch
amount before registra-
tion (Upper, Thin paper)
FEED-ADJ> MD-LP1TH
FEED-ADJ> MD2LP1TH *
When skew occurs - If the value is too large, paper
wrinkles or paper bending
may occur.
- Default setting for thin paper
mode: -46 (arch amount be-
fore registration: 0 mm)
