Items
Service Mode
(COPIER> ADJUST)
Use case Remarks
Adjusting the arch
amount before registra-
tion (Upper, except Thin
paper)
FEED-ADJ> MD-LP1
FEED-ADJ> MD2-LP1 *
When skew occurs - If the value is too large, paper
wrinkles or paper bending
may occur.
- Default setting except for thin
paper mode: 0 (arch amount
before registration: 4.6mm)
Adjusting the arch
amount before registra-
tion (Middle, Thin paper)
FEED-ADJ> MD-LP2TH
FEED-ADJ> MD2LP2TH *
When skew occurs - If the value is too large, paper
wrinkles or paper bending
may occur.
- Default setting for thin paper
mode: -46 (arch amount be-
fore registration: 0 mm)
Adjusting the arch
amount before registra-
tion (Middle, except Thin
paper)
FEED-ADJ> MD-LP2
FEED-ADJ> MD2-LP2 *
When skew occurs - If the value is too large, paper
wrinkles or paper bending
may occur.
- Default setting except for thin
paper mode: 0 (arch amount
before registration: 4.6mm)
Adjusting the arch
amount before registra-
tion (Lower, Thin paper)
FEED-ADJ> MD-LP3TH
FEED-ADJ> MD2LP3TH *
When skew occurs - If the value is too large, paper
wrinkles or paper bending
may occur.
- Default setting for thin paper
mode: -46 (arch amount be-
fore registration: 0 mm)
Adjusting the arch
amount before registra-
tion (Lower, except Thin
paper)
FEED-ADJ> MD-LP3
FEED-ADJ> MD2-LP3 *
When skew occurs - If the value is too large, paper
wrinkles or paper bending
may occur.
- Default setting except for thin
paper mode: 0 (arch amount
before registration: 4.6mm)
Adjusting the paper sur-
face position (Upper).
FEED-ADJ> MD-PKLV1
FEED-ADJ> MD2PKLV1 *
- When a pickup failure occurs
- When double feed occurs
If the value is too large, double
feed may occur. If the value is
too small, pickup failure may
occur.
Adjusting the paper sur-
face position (Middle).
FEED-ADJ> MD-PKLV2
FEED-ADJ> MD2PKLV2 *
- When a pickup failure occurs
- When double feed occurs
If the value is too large, double
feed may occur. If the value is
too small, pickup failure may
occur.
Adjusting the paper sur-
face position (Lower).
FEED-ADJ> MD-PKLV3
FEED-ADJ> MD2PKLV3 *
- When a pickup failure occurs
- When double feed occurs
If the value is too large, double
feed may occur. If the value is
too small, pickup failure may
occur.
Adjusting the arch
amount before registra-
tion of the Horizontal
Path
FEED-ADJ> MD-LP4
FEED-ADJ> MD2-LP4 *
- When skew occurs
- When paper damage occurs
- If the value is too large, paper
wrinkles or paper bending
may occur.
- The setting is applied regard-
less of the pickup location.
Adjustment of double
feed detection threshold
value (Upper, film)
SENS-ADJ> MD-DP-F1
SENS-ADJ> MD2DP-F1 *
- When double feed occurred but not de-
tected
- When double feed wrongly detected even
it did not occur
Adjustment of double
feed detection threshold
value (Lower, film)
SENS-ADJ> MD-DP-F3
SENS-ADJ> MD2DP-F3 *
- When double feed occurred but not de-
tected
- When double feed wrongly detected even
it did not occur
Adjustment of double
feed detection threshold
value (Through Path,
film)
SENS-ADJ> MD-DP-F4 - When double feed occurred but not de-
tected
- When double feed wrongly detected even
it did not occur
5. Adjustment
167
