Canon E1 - Removing the Deck Front Cover

■ Procedure
1. Remove the Deck Right Lower Cover [1].
• 2 Screws [2]
[2]
2x
[1]
Removing the Deck Front Cover
■ Preparation
1. Release the lock to open the target Deck. “Releasing the Deck” on page 77
■ Procedure
NOTE:
The removal procedure of the Deck Front Cover from the Upper Deck is described below. The procedure of the Middle and Lower
Decks is the same.
1. Draw ruled lines at the position of the Deck Front Cover installed [1], and then loosen 5 Screws [2].
4. Parts Replacement and Cleaning
84
