Items
Service Mode
(COPIER> OPTION)
Use case Remarks
Setting of MD (Lower)
Pickup Roll engage/
disengage
FEED-SW> MD-PSP3
FEED-SW> MD2-PSP3 *
When Pickup Roller trace occurs on the
2nd sheets and later
If the machine is continued to
be used while the setting val-
ue is 1, the life of the solenoid
becomes shorter.
Setting limit release of
Escape Tray 2: MD
FEED-SW> MD-FULL To clear the limit on the full count of paper
discharged to the Escape Tray on the Multi
Deck.
- The user mode (immediate
stop) setting takes prece-
dence.
- A jam may occur in The flap-
per section.
Adjusting the airflow
amount of the Air Floata-
tion Fan (Upstream) of
the Upper Deck
FEED-SW> MD-ALVU1
FEED-SW> MD2ALVU1 *
When double-feed occurs. If the value is large, uneven
transfer may occur. If the val-
ue is small, double feed may
occur.
Adjusting the airflow
amount of the Air Floata-
tion Fan (Downstream) of
the Upper Deck
FEED-SW> MD-ALVD1
FEED-SW> MD2ALVD1 *
When double-feed occurs. If the value is large, uneven
transfer may occur. If the val-
ue is small, double feed may
occur.
Adjusting the airflow
amount of the Air Floata-
tion Fan (Upstream) of
the Middle Deck
FEED-SW> MD-ALVU2
FEED-SW> MD2ALVU2 *
When double-feed occurs. If the value is large, uneven
transfer may occur. If the val-
ue is small, double feed may
occur.
Adjusting the airflow
amount of the Air Floata-
tion Fan (Downstream) of
the Middle Deck
FEED-SW> MD-ALVD2
FEED-SW> MD2ALVD2 *
When double-feed occurs. If the value is large, uneven
transfer may occur. If the val-
ue is small, double feed may
occur.
Adjusting the airflow
amount of the Air Floata-
tion Fan (Upstream) of
the Lower Deck
FEED-SW> MD-ALVU3
FEED-SW> MD2ALVU3 *
When double-feed occurs. If the value is large, uneven
transfer may occur. If the val-
ue is small, double feed may
occur.
Adjusting the airflow
amount of the Air Floata-
tion Fan (Downstream) of
the Lower Deck
FEED-SW> MD-ALVD3
FEED-SW> MD2ALVD3 *
When double-feed occurs. If the value is large, uneven
transfer may occur. If the val-
ue is small, double feed may
occur.
Setting the double feed
detection threshold val-
ue : Upper
FNC-SW> MD-DPLV1
FNC-SW> MD2DPLV1 *
When double feed is incorrectly detected
with special paper not defined in the spec-
ifications
In the case of highlands, be
sure to set MD-DUP-H in ad-
vance.
Setting the double feed
detection threshold val-
ue : Lower
FNC-SW> MD-DPLV3
FNC-SW> MD2DPLV3 *
When double feed is incorrectly detected
with special paper not defined in the spec-
ifications
In the case of highlands, be
sure to set MD-DUP-H in ad-
vance.
Setting the double feed
detection threshold val-
ue : Through Path
FNC-SW> MD-DPLV4 When double feed is incorrectly detected
with special paper not defined in the spec-
ifications
In the case of highlands, be
sure to set MD-DUP-H in ad-
vance.
Setting the double feed
detection highland mode
FNC-SW> MD-DUP-H
FNC-SW> MD2DUP-H *
When the installation site is above the alti-
tude of 2000 meters at installation
Setting the curl correct at
Upper Deck pickup
CST> D7-CURL
CST> D11CURL *
Upon user's request
Setting the curl correct at
Middle Deck pickup
CST> D8-CURL
CST> D12CURL *
Upon user's request
Setting the curl correct at
Lower Deck pickup
CST> D9-CURL
CST> D13CURL *
Upon user's request
Setting the area-specific
standard size paper cat-
egory 1 used in Upper
Deck
CST> CST5-U1
CST> CST8-U1 *
When setting area-specific standard size
paper
Setting the area-specific
standard size paper cat-
egory 3 used in Upper
Deck
CST> CST5-U3
CST> CST8-U3 *
When setting area-specific standard size
paper
5. Adjustment
170
